Tesla Battery Day: a raft of tech advances will deliver cost reductions worth waiting for

We’re used to extremely ambitious (not to say unrealistic) timelines from Tesla—a new Terafactory in a few months, a fleet of Robotaxis before the end of the year—so Elon Musk’s measured, conservative predictions at the long-awaited Battery Day event caught the mainstream press on the wrong foot.

“In three years…we can do a $25,000 car that will be basically on par [with], maybe slightly better than, a comparable gasoline car,” said the uncharacteristically cautious Musk. Three years? Slightly better? As one analyst put it, to be a “long-term investor” these days means looking ahead one year. This wasn’t the blockbuster news the masses were expecting, and TSLA stock got hammered.

It may just be that Musk has matured, and adopted a new policy of under-promising and over-delivering. Another thing that’s going on here is that, as usual, our colleagues in the general-interest and financial media have missed the real implications of Tesla’s news. How fortunate that we more tech-savvy EV journalists are here to enlighten them, and you, dear readers.

So, to sum up the message of Battery Day in plain language: The Oil Age is ending.

The main event was the unveiling of Tesla’s new, in-house battery cell, dubbed the Tesla 4680 cell in honor of its dimensions (46 mm by 80 mm). The larger cell offers five times the energy capacity, and six times the power capacity of Tesla’s previous cells (capacity, not density—Tesla did not reveal the amount of improvement in energy density).

Simply making the cell larger allows an increase in capacity and a reduction in cost. Tesla claims that the larger form factor will increase vehicle range by 16%, and reduce cost per kWh by 14%. However, making the cell larger makes thermal management more challenging, which Tesla has dealt with by creating a new tabless cell design that offers much less resistance compared to existing designs.

The new cell design is only part of the story. Elon Musk and Drew Baglino, Tesla’s Senior VP of Powertrain and Energy Engineering, described important innovations in at least four other aspects of battery production:

  • a new type of silicon that will allow more Si to be used in the anode in place of graphite, reducing costs by 5%
  • a new cathode production process that eliminates wastewater and uses nickel more efficiently (12% cost savings here)
  • a new battery pack that forms a structural part of the vehicle, linking the large underbody castings, which could reduce overall vehicle mass by 10%
  • improved and simplified manufacturing processes, including the dry coating electrode process pioneered by Maxwell, which Elon Musk said is “close to working,” and a super high-speed assembly process that is supposed to increase production line output sevenfold

By combining all these innovations, Tesla hopes to cut the cost per kWh of battery packs in half within the next three years or so. Will that get us to the Grail? Absolutely. Industry observers are predicting that the EV industry will breach the holy $100/kWh number by 2023, but some believe that Tesla is already very close to that figure. The new, more circumspect Musk didn’t specify an exact price target, but he did say that Tesla’s three-year plan will bring the price below Grail level.

Napkins covered with scrawled math are all over the table. The Verge predicts Tesla’s $25,000 EV will have a $6,000 battery pack (a reduction of almost 100% from current costs in the industry). Electrek’s Fred Lambert, a keen Tesla-watcher, is more sanguine—he believes Tesla’s current pack-level cost is around $110/kWh, so halving the cost would put the price of a 50 kWh pack at only $2,500—a tenth of the cost of the original Model S pack.

How would a $25,000 EV (which might just be called Model 2) affect the global auto industry? According to The Verge, the average EV on the US market cost $55,600 in 2019, considerably pricier than the average dinosaur burner at $36,600. The numbers represent some sweeping generalizations and a large dose of uncertainty, but if Tesla comes anywhere close to reaching its announced goals, we should start to see gas cars sitting out in the rain with the last of the cathode-ray-tube TVs sometime in 2023.

Tesla will build the next-gen batteries in Fremont. The company hopes to be producing 10 GWh per annum within about a year, 100 GWh by 2023, and 3,000 GWh by 2030.

Massive vertical integration is the order of the day. Tesla is talking about mining its own lithium (and, naturally, making production of the light white stuff more efficient, cheaper and greener).

Every Tesla event has to have a bit of lagniappe, and this time around it was the Model S Plaid, which will be the highest-performance Model S ever. In fact, the tri-motor, all-wheel drive sedan will be the quickest production car ever, with a 0-60 mph time of less than two seconds, as well as a 200 mph top speed, over 520 miles of range, and a starting price of $139,990. The super-Tesla isn’t at the top of the priority list, however—Musk confirmed that production is expected in “late 2021.”

Sources: Tesla, Electrek, The Verge, EVannex
