Yamaichi Electronics, a manufacturer of test and burn-in sockets, connectors and test contacts, has released the newest version of its Y-Lock Pullforce connector system to meet the requirements of battery applications.

The flexible flat cable (FFC) or the flexible printed circuit board (FPC) is inserted into the connector using the pre-assembled stiffener. The Y-Lock V4 series has a double locking function, via two lateral locking hooks and a central locking mechanism on the long side of the insulator.

The two-part stiffener design ensures that the FFC or FPC are protected against contact, so that the cable can be handled safely during servicing. This feature also ensures that the plug cannot be inserted at an angle or upside down, preventing short circuits. The stiffener can be permanently locked to the connector by an additional plastic part.

The Y-Lock V4 series is available with gold or tin plating. It is currently available in a 90° version and its 4.5 mm height is well suited to the tight installation spaces in battery applications.

The connector system is available with different contact spacings: 1.0 mm, 1.2 mm, 1.8 mm and 2 mm for various clearance and creepage distances.

Source: Yamaichi Electronics
