Liquid Cooling For EV Charging And How To Spec Connectors

Presented by:

  • Beth Langer, Engineering Manager, Thermal Management at CPC

Session Banner

Product Demo

Sep 3, 2020, 12:30 pm EDT

The more power used to deliver faster charging, the more heat that is generated. Effective thermal management via liquid cooling deals with the heat and these systems need couplings or secure connectors in order to deliver reliable ongoing operation of EV charging stations and EV battery systems.

Attention to thermodynamic principles is critical yet the appropriate specifications for the components in charging stations are often poorly understood. Flow rate, temperature and pressure requirements, side load, chemical compatibility, seal and valve types, and overall quick disconnect structure and material (e.g., stainless steel, brass and newer high-performance engineered polymers) all have significant impact on liquid cooling system functionality. Purpose-built couplings support the quicker charging and fluid handling components and are often incorporated right alongside critical electronic equipment or components. These connectors or quick disconnects (QDs) are not all created equal...

Refresh yourself on calculations to apply and learn pitfalls to avoid in designing a system and specifying critical components like connectors.

About the presenter:
Beth Langer is the Engineering Manager in the Thermal Management Business Unit at CPC. She earned her Bachelor and Master of Science degrees in Mechanical Engineering from the University of St. Thomas in St. Paul, MN. Over the course of her career, she has been responsible for product design, reliability and technical innovation for industrial products. Besides leading design solutions that serve CPC customers, she is an active consulting member on ASHRAE and OCP committees.
