Free EV Engineering Webinar:

Power Loss Analysis And Efficiency Mapping for EV Motors

Presented by:

  • Hidekazu Masuda, Product Marketing Specialist, Hioki USA

Session Banner

Sep 17, 2025, 12:30 pm EDT

This webinar will introduce a method for evaluating EV motor efficiency by separating electrical losses using the Hioki PW8001 power analyzer. Focusing on Permanent Magnet Synchronous Motors (PMSMs) under real operating conditions, the method analyzes copper and iron losses based on fundamental and harmonic power components. It reveals how increased inverter switching frequency leads to higher iron losses within the motor.

Join us to learn how, with wideband accuracy and User Defined Function (UDF) support, the PW8001 enables automated, real-time loss analysis. Efficiency and loss maps across torque-speed ranges support informed motor design decisions.


Now available to watch on-demand: Register for this webinar to watch a recording of the presentation and audience Q&A, and download the presentation slides.


Register





All Sessions: September 2025 Conference


Free EV Engineering Webinars
The sessions from our September 2025 EV Engineering Conference are now available to view on-demand. Register for a session below to watch the recording and download the presentation.
